SCADACore Cloud-Ready
Cloud-Ready Products and Packages delivers complete end-to-end system that brings sensor data to you in a simple packaged solution.
Pumpjack Callout
Satellite Remote Monitoring Solution
The Pumpjack Callout is a Class I Div 1, magnetic-mount, satellite monitoring solution with a built-in solar panel and batteries, ideal for monitoring the run status of your pumpjacks.
Monitor the run status using vibration or engine oil pressure
Satellite monitoring for pumpjacks that senses the vibration of the motor
Vibration Sensor, 2 Digital Inputs, GPS
Alarm Callout / Alarm Notifications via SMS, Email, and / or Voice Messages
Escalating call lists can be set up to notify available staff of shutdowns
Built-in Solar Panel and rechargeable NiMH Battery
Compressor Callout
Satellite Remote Monitoring Solution
The Compressor Callout is a Class I Div 1, magnetic-mount, satellite monitoring solution with a built-in solar panel and batteries, ideal for monitoring the run status of your compressors.
Monitor the run status using vibration or digital input
Satellite monitoring for compressor that senses the vibration of the motor
Vibration Sensor, 2 Digital Inputs, GPS
Alarm Callout / Alarm Notifications via SMS, Email, and / or Voice Messages
Escalating call lists can be set up to notify available staff of shutdowns
Built-in Solar Panel and rechargeable NiMH Battery
Tank Level Cellular Package
Cellular Gateway | Ultrasonic Sensor | Web-Based Data Access
Complete tank level monitoring package includes cellular modem and ultrasonic tank level sensor. Turnkey solution with web-based data access. Access tank level data anytime, anywhere with an internet connection.
Monitoring for Tank Level, Water Level, and More
High and Low Level Notifications via SMS, Email, and / or Voice
Cellular Gateway / Modem: Embedded 2G, 3G, LTE
Replaceable Battery with ~2 Year Life, Solar-Panel Add-On Available
Intrinsically Safe: Class 1 Div 2 Comms, Class 1 Div 1 Sensor
Sensor Range: 1 to 25 ft, 30.5cm to 762cm
Operating Temperature: -40˚ C to +85˚ C
Tank Level Satellite Package
Satellite Transceiver | Ultrasonic Sensor | Web-Based Data Access
Complete tank level monitoring package includes satellite transceiver and ultrasonic tank level sensor. Turnkey solution with web-based data access. Browse through thousands of tanks and their levels with SCADACore Live.
Monitoring for Tank Level, Water Level, and More
High and Low Level Notifications via SMS, Email, and / or Voice
Satellite Transceiver, Elevation angle: -5° to +90°
Intrinsically Safe: Class 1 Div 2 Comms, Class 1 Div 1 Sensor
Dial-in rotary impactor
Sensor Range: 1 to 25 ft, 30.5cm to 762cm
Operating Temperature: -40˚ C to +85˚ C
